Hastelloy Flanges Manufacturer in India

Hastelloy Flanges

Table of content

Hastelloy Flanges Manufacturer, Hastelloy Blind Flange, Hastelloy Flanges, Hastelloy C276, Hastelloy C276 Pipe Flanges,B2 Flanges Manufacturer, B472/564 UNS N10276, C22, ASTM SB 160 Manufacturer in India

Sysco Fittings is a leading of Hastelloy Flanges in Manufacturer India. We produce a great quality Hastelloy Blind Flange, Hastelloy Socket Weld Flange, Hastelloy Slip-On Flange, and Hastelloy Weld Neck Flange. The manufacturing design of high-performance flanges achieves superior strength through resistance to extreme temperatures and high pressures as well as highly corrosive environments where they demonstrate durable properties against oxidation and pitting and stress corrosion cracking. Hastelloy C276 Pipe Flanges serve piping systems in chemical processing and aerospace applications together with marine and power generation and pharmaceutical industries by establishing leak-free secure connections. Sysco Fittings makes ISO 9001, ISO 14001, and ISO 45001-compliant Hastelloy products under ISO certification standards to serve demanding worldwide industries.

Hastelloy Flanges Manufacturer

Hastelloy Alloy B2 Flanges, ASTM B564 Hastelloy B2 Flanges, Hastelloy B2 Plate Flanges, Hastelloy C22 Slip On Flange Supplier in India


Sysco Fittings is a trusted Hastelloy Flanges Supplier and Manufacturer India. We provide our customers with high-quality Hastelloy Long Weld Neck Flanges, Hastelloy Reducing Flanges, and Hastelloy Lap Joint Flanges. These Hastelloy C22 Slip On Flange are designed for use under high pressure in hot conditions while bearing corrosive substances because they exhibit remarkable durability together with resistance to pitting corrosion and oxidation and stress corrosion cracking effects. The chemical processing industry relies on our Hastelloy B2 Plate Flanges to create leak-free critical connections for their applications in power generation and pharmaceutical production, as well as aerospace and marine fields. Sysco Fittings produces Hastelloy solutions under ISO 9001, ISO 14001, and ISO 45001 certification standards that achieve international market trust across worldwide industries. We are also certified Hastelloy Forged Fittings Manufacturers in India.


Fast
Delivery

We ensure fast and efficient delivery of our products worldwide.

24/7
Service

Our team is always available for inquiries, order processing, and technical assistance

Custom
Fabrication

We offer custom fabrication for our products, tailored to your specifications.

Quality
Testing

We conduct quality testing to ensure the highest standards in our products.



Specifications Of Hastelloy Flanges


Standard ASTM B564 / ASME SB564
Dimensions EN1092, EN Flanges, API7S-43, BS4504, B16.47 Series A & B, ASME Flanges, BS 10,ANSI/ASME B16.5, EN-1092, DIN Flanges, MSS S44, ISO70051, DIN, ASME/ANSI B16.5/16.36/16.47A/16.47B, API7S-15, API605, BS1560-3.1, JISB2220, ANSI Flanges
Size 1/2″ (15 NB) to 48″ (1200NB), DN10~DN5000
Pressure Rating Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
Pressure Calculation in DIN 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
JIS 16 K, 5K, 10 K, 20 K, 30 K, 40 K, 63 K
Flange Connection / Flange Face Type Lap-Joint Face (LJF), Large Male-Female (LMF), Flange Pipe., Small Male-Female (SMF), Groove, Ring Type Joint (RTJ), Flat Face (FF),Raised Face (RF), Small Tongue, Large Tongue & Groove
Types of Flanges Screwed / Threaded / Forged / Plate
Test Of Flange Direct-reading Spectrograph, Ultrasonic flaw detector, Magnetic particle detector, X-ray detector, Hydrostatic testing machine.
Production Technique Used Heat treated, Forged and Machined
Grades F201, F202, F301, F302, F304, F304L, F309, F310, F316, F316L, F316LN, F317L, F321, F347, 405, 409, 410, 420, 430, 440C, F904L

Types of Hastelloy Flanges

Hastelloy Blind Flange

Hastelloy Blind Flange

Hastelloy Socket Weld Flange

Hastelloy Socket Weld Flange

Hastelloy Steel Slip on Flange

Hastelloy Steel Slip on Flange

Hastelloy Weld Neck Flanges

Hastelloy Weld Neck Flanges

Hastelloy Lap Joint Flange

Hastelloy Lap Joint Flange

Hastelloy Reducing Flanges

Hastelloy Reducing Flanges

Hastelloy Long Weld Neck Flange

Hastelloy Long Weld Neck Flange

Mechanical Properties of Hastelloy Flanges

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C276 8.89 g/cm3 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52,000 , MPa – 355 40 %
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %
Hastelloy B2 9.2 g/cm3 1370 °C (2500 ºF ) Psi – 1,10,000 , MPa – 760 Psi – 51000 , MPa – 350 40 %

Chemical Properties of Hastelloy Flanges

Grade C Mn Si S Co Ni Cr Fe Mo P
C276 0.010 max 1.00 max 0.08 max 0.03 max 2.50 max 50.99 min* 14.50 – 16.50 4.00 – 7.00 15.00 – 17.00 0.04 max
C22 0.010 max 0.50 max 0.08 max 0.02 max 2.50 max 50.015 min* 20.00 – 22.50 2.00 – 6.00 12.50 – 14.50 0.02 max
B2 0.02 max 1.0 max 0.1 max 0.03 max 1.0 max Bal 1.0 max 2.0 max 26 – 30 0.04 max

Dimensions of Hastelloy Flanges

NPS
(in.) 		Hastelloy Flange Dimensions
Dia. of
Flange
(in.) 		No.
of
Bolts		 Dia. of
Bolts
(in.) 		Dia. of
Bolt Holes
(in.) 		Bolt
Circle
(in.)
1/4 3-3/8 4 1/2 0.62 2-1/4
1/2 3-1/2 4 1/2 0.62 2-3/8
3/4 3-7/8 4 1/2 0.62 2-3/4
1 4-1/4 4 1/2 0.62 3-1/8
1-1/4 4-5/8 4 1/2 0.62 3-1/2
1-1/2 5 4 1/2 0.62 3-7/8
2 6 4 5/8 0.75 4-3/4
2-1/2 7 4 5/8 0.75 5-1/2
3 7-1/2 4 5/8 0.75 6
3-1/2 8-1/2 8 5/8 0.75 7
4 9 8 5/8 0.75 7-1/2
5 10 8 3/4 0.88 8-1/2
6 11 8 3/4 0.88 9-1/2
8 13-1/2 8 3/4 0.88 11-3/4
10 16 12 7/8 1 14-1/4
12 19 12 7/8 1 17
14 21 12 1 1.12 18-3/4
16 23-1/2 16 1 1.12 21-1/4
18 25 16 1-1/8 1.25 22-3/4
20 27-1/2 20 1-1/8 1.25 25
24 32 20 1-1/4 1.38 29-1/2

Contact us for a quotation right now!!

+91 98695 07037 export@syscoshims.com
Various Types Industry

Applications of Hastelloy Flanges

  • Oil & Gas Industry

  • Water Treatment Plants

  • Chemical Processing

  • Power Plants

  • Pharmaceutical Industry

  • Food & Beverage Industry

  • Marine & Shipbuilding

  • Mining & Metallurgy Industry

Packaging of Hastelloy Flanges


The packaging of Hastelloy Flanges is fundamentally important to guarantee safety in transit, with no loss in product quality or damage. Sysco Fittings follows packing standards recommended internationally which will protect Fittings from corrosion, impact, and the effects of the environment.

  • Wooden Crates
  • Pallet Packaging
  • Carton Packaging
  • Bubble Wrap Packaging
  • Plastic Wrapping
  • Box Packaging
  • Custom Packaging
  • Poly Bag Packaging
Packing of Flanges Fittings

Other types of Hastelloy Flanges

Other Types of Products

Our

*Other Types of Hastelloy Flanges
View Products
  • Hastelloy RTJ Flanges
  • Hastelloy Spectacle Blind Flanges
  • Hastelloy Nipo Flanges
  • Hastelloy Raised Face Flange
  • Hastelloy Spectacle Blind Flanges
Other Types of Products

Our

*Other Types of Hastelloy Flanges
View Products
  • Hastelloy Orifice Flange
  • Hastelloy Steel Long Weld Neck Flanges
  • Hastelloy Steel Plate Flanges
  • Hastelloy Threaded Flanges
  • Hastelloy Slip on Flat Face Flange
